FTTH GJYXCH GJYXFCH G652D G657A1 A2 Singlemode Fiber Drop Cable FTTH Cable 1 2 4 Core Fiber Optic Cable
Detail produk:
| Tempat asal: | CINA |
| Nama merek: | TTI Fiber |
| Sertifikasi: | ISO 9001, ISO 14001, REACH， ROHS, CE and CPR certificates |
| Nomor model: | GJYXCH Kabel Drop Serat Optik |
Syarat-syarat pembayaran & pengiriman:
| Kuantitas min Order: | 1000 |
|---|---|
| Harga: | dapat dinegosiasikan |
| Kemasan rincian: | Paket Standar (Mendukung OEM/ODM) |
| Waktu pengiriman: | 5-8 hari kerja |
| Syarat-syarat pembayaran: | D/A, D/P, T/T... |
| Menyediakan kemampuan: | 100.000 meter |
|
Informasi Detail |
|||
| Nama Produk: | Kabel Drop Serat Optik GJYXCH | Aplikasi: | Kabel serat optik luar ruangan |
|---|---|---|---|
| Warna: | Hitam | Bahan: | LSZH PE |
| Tipe serat: | G652D G657A1 G657A2 | Sertifikasi: | ROHS,CE,ISO14001,ISO9001 |
| Menggunakan: | Fttx | Panjang: | Disesuaikan |
| Kontrol kualitas: | Tes 100% sebelum pengiriman | Kemasan: | Domba Kayu |
| Menyoroti: | FTTH singlemode fiber drop cable,G652D fiber optic cable,4 core FTTH cable with warranty |
||
Deskripsi Produk
FTTH GJYXCH GJYXFCH G652D G657A1 A2 Singlemode Fiber Drop Cable FTTH Cable 1 2 4 Core Fiber Optic Cable
Indoor Outdoor FTTH G657A2 GJYXFCH 1KM Outdoor Fiber Optic Drop Cable
GJYXCH Drop Cable Construction / Cross Sectional Diagram
Technical Specification
| Items | Specification |
|---|---|
| Fiber count | 1/2/4F |
| Fiber | Out diameter(±5μm): 250 |
| Outer sheath |
Self supporting element: 1.0mm Steel wire Tensile element: 2*0.4mm Steel wires Sheath material: LSZH Color: Black |
| Out diameter | 5.1(±0.2)*2.0(±0.1) mm |
| Cable weight(kg/km) | 22 |
Optical Fiber Specifications
| Fiber type | G652D (1310/1550nm) | G657A1 (1310/1550nm) | G657A2 (1310/1550nm) |
|---|---|---|---|
| Attenuation |
Typical: 0.36/0.22 Maximum: 0.5/0.4 |
Typical: 0.36/0.22 Maximum: 0.5/0.4 |
Typical: 0.36/0.22 Maximum: 0.5/0.4 |
| Zero Dispersion Slope | ≤0.091 ps/km*nm2 | ≤0.092 ps/km*nm2 | ≤0.092 ps/km*nm2 |
| Dispersion(1285~1340nm) | -3.5 - 3.5ps/(nm*km) | -3.5 - 3.5ps/(nm*km) | -3.5 - 3.5ps/(nm*km) |
| Mode field Diameter(@1300nm) | 9.3±0.4 µm | 8.8±0.4 µm | 8.8±0.4 µm |
| Cutoff wavelength cable(nm) | ≤1260 nm | ≤1260 nm | ≤1260 nm |
| Min bend radius(mm) | 16 mm | 10 mm | 7.5 mm |
| Cladding diameter(µm) | 125±1.0 | 125±1.0 | 125±1.0 |
Mechanical and Environmental Performance of the Cable
| Mechanical properties | Installation | Operation |
|---|---|---|
| Tensile strength | 300N | 600N |
| Min bend radius | 15mm | 30mm |
| Crush resistance | 2000N/100mm | |
The mechanical properties of other optical fibers and cables shall meet international standards of IEC 60794.
Fiber Optical Cable Temperature Specifications
| Transportation temperature | -20℃~+60℃ |
| Storage temperature | -20℃~+60℃ |
| Installation temperature | -20℃~+60℃ |
| Operation temperature | -20℃~+60℃ |
